Subject Topic: JTD EGR Valve Location Post ReplyPost New Topic
Author
Message << Prev Topic | Next Topic >>
prontopunto
Junior Alfisti
Junior Alfisti
Avatar

Joined: 15 July 2006
Online Status: Offline
Posts: 20
Posted: 26 January 2008 at 15:02 | IP Logged Quote prontopunto

This car is turning into a nightmare!!

A smokey engine and lack of power below 2000 revs is down to the EGR valve, or so I'm told.

The question is, where is it and what does it look like?? I'm going to try cleaning it

It's a '04 1.9 JTD 16v

__________________

2004 156 1.9 JTD 16v Sportwagon
1937 Scott Flying Squirrel
1987 Golf GTi
Back to Top View prontopunto's Profile Search for other posts by prontopunto

Black Beauty
Tourismo (guest)
Tourismo (guest)
Avatar
Rnr-up helpful 06, Pin 07’08, Banned’09-

Joined: 25 June 2005
Location: Ireland
Online Status: Offline
Posts: 20134
Posted: 26 January 2008 at 16:37 | IP Logged Quote Black Beauty

one of these threads
Back to Top View Black Beauty's Profile Search for other posts by Black Beauty

prontopunto
Junior Alfisti
Junior Alfisti
Avatar

Joined: 15 July 2006
Online Status: Offline
Posts: 20
Posted: 26 January 2008 at 18:12 | IP Logged Quote prontopunto

I've found it now and stripped it. Full of soot and siezed. Washed it with petrol, cleaned out the manifold and WD40'd the valve. Put it back together and it runs superb!!

I also cleaned the MAF sensor of oil. Might have been part of the problem, but all done for £00. Better than the £200 plus I was quoted to replace the bits!!



__________________

2004 156 1.9 JTD 16v Sportwagon
1937 Scott Flying Squirrel
1987 Golf GTi
Back to Top View prontopunto's Profile Search for other posts by prontopunto

Black Beauty
Tourismo (guest)
Tourismo (guest)
Avatar
Rnr-up helpful 06, Pin 07’08, Banned’09-

Joined: 25 June 2005
Location: Ireland
Online Status: Offline
Posts: 20134
Posted: 26 January 2008 at 18:18 | IP Logged Quote Black Beauty

well done ..... great sense of satisfaction, ain't it?
Back to Top View Black Beauty's Profile Search for other posts by Black Beauty

Gadget_Daddy
Junior Alfisti
Junior Alfisti


Joined: 19 December 2007
Online Status: Offline
Posts: 181
Posted: 26 January 2008 at 23:03 | IP Logged Quote Gadget_Daddy

yey i also know that feeling after recently doing exactly the same...well done
Back to Top View Gadget_Daddy's Profile Search for other posts by Gadget_Daddy

prontopunto
Junior Alfisti
Junior Alfisti
Avatar

Joined: 15 July 2006
Online Status: Offline
Posts: 20
Posted: 27 January 2008 at 19:22 | IP Logged Quote prontopunto

For those of you not sure of it's location, I shall post a couple of pics later.

If you were to look into the engine bay, the EGR valve sits at the back of the inlet manifold to the right hand side. It is black, ribbed and with a cable connector on one end. The other end bolts to a casing on the manifold, with a pipe running from the bottom of the case and down to the exhaust manifold.

Photo's later, when it will all become obvious!!

__________________

2004 156 1.9 JTD 16v Sportwagon
1937 Scott Flying Squirrel
1987 Golf GTi
Back to Top View prontopunto's Profile Search for other posts by prontopunto

Gadget_Daddy
Junior Alfisti
Junior Alfisti


Joined: 19 December 2007
Online Status: Offline
Posts: 181
Posted: 28 January 2008 at 01:16 | IP Logged Quote Gadget_Daddy

not on the 2.4 jtd its at the front of the engine in the middle
Back to Top View Gadget_Daddy's Profile Search for other posts by Gadget_Daddy

Sam37
Junior Alfisti
Junior Alfisti
Avatar

Joined: 23 September 2007
Location: United Kingdom
Online Status: Offline
Posts: 1401
Posted: 28 January 2008 at 10:02 | IP Logged Quote Sam37

On the 2.4 its that circular bit on the closest edge of the engine cover (bottom middle of pic), with the metal braided pipe going around the side to the air inlet:



__________________
1999 156 2.4 JTD
Back to Top View Sam37's Profile Search for other posts by Sam37

wrinx
Junior Alfisti
Junior Alfisti
Avatar

Joined: 27 March 2004
Location: United Kingdom
Online Status: Offline
Posts: 168
Posted: 29 January 2008 at 09:32 | IP Logged Quote wrinx

Gadget_Daddy wrote:
not on the 2.4 jtd its at the front of the engine in the middle


Yes, on the 136 engine (picture above), but on the 140 engine you have to follow the metal pipes round to the back of the head.

No idea about the 150 and later engines...but would guess they share they 140 set up.

wrinx

__________________
Back to Top View wrinx's Profile Search for other posts by wrinx Visit wrinx's Homepage

Sidelights
Junior Alfisti
Junior Alfisti
Avatar

Joined: 05 April 2008
Location: United Kingdom
Online Status: Offline
Posts: 9
Posted: 22 October 2008 at 18:39 | IP Logged Quote Sidelights

I think you'll find this of help:
       http://forum.alfa156.net/forum/forum_posts.asp?TID=48465&PN= 1&TPN=1

__________________
2.4 JTD Lusso complete with whale tail
Back to Top View Sidelights's Profile Search for other posts by Sidelights
