Subject Topic: Rough Guide to GTA-ing headlights [PIC’s] Post ReplyPost New Topic
Author
Message << Prev Topic | Next Topic >>
Black Beauty
Tourismo (guest)
Tourismo (guest)
Avatar
Rnr-up helpful 06, Pin 07’08, Banned’09-

Joined: 25 June 2005
Location: Ireland
Online Status: Offline
Posts: 20134
Posted: 29 December 2008 at 14:44 | IP Logged Quote Black Beauty

Remove front Bumper:

* Wheel arch top & bottom bolt both sides

* Left, centre & Right grill sections [ 6 screws ]

* 4 Torx T30 bolts in top of bumper



* 2 Torx T30s INSDIE of each side of the front bumper & 1 10mm nut, best to access from apit or pulling away the wheel arch liner



* unclip wires to fog lights



Remove Headlights:

Once the bumper is off there are 2 10mm nuts & 3 sets of wires. Use a flat ehaded screw driver to push IN the metal U spring/clamp & then pull BACK the connector

Shows the 10mm nuts, top & bottom


Split the sealant around the lense using a stanley knife:


Remove the lense by unclipping each clip, there are 5:
:



Removing the surround away from headlight:



All apart:


Remove the old sealant from lense & headlight backing:


Use 400 grade to remove the chrome paint off the surrounds & primer:





My lenses were badly marked & the lacquer was starting to peel of, similar to Redd's 1st picture

So with the lenses off its an idea time to re-furbish the lenses:

Using Redd's guide

This was one of my car's lense at the P1200 stage:



B-B gets a brain wave & decides to try the Halford Power Buffer + Brasso + Cif to do final smoothing:



After 'power-buffing'



Clear'd Lense



Surrounds 'matt-black'


Have one lense to do, final coating of matt black on the surrounds & then a re-seal using fill-grip stuff

Update:
Last coat of Matt Black sprayed on, clean cleaned up & sealed with 'Evo-Grip'












Edited by Black Beauty on 15 January 2009 at 16:42
Back to Top View Black Beauty's Profile Search for other posts by Black Beauty

bannowhog
Tourismo (guest)
Tourismo (guest)
Avatar
Pin 08, Banned 2011-

Joined: 26 June 2008
Location: Ireland
Online Status: Offline
Posts: 1491
Posted: 29 December 2008 at 21:34 | IP Logged Quote bannowhog



Great job again Pat, yes, more black, you can never have it black enough.

I will have the gripfill tomorrow for ya.

__________________
BURIED CITY CUSTOMS
MOTORCYCLE ENGINEERING
Back to Top View bannowhog's Profile Search for other posts by bannowhog Visit bannowhog's Homepage

156-2.5-V6
Senior Alfisti
Senior Alfisti
Avatar
Best Newcomer 07, Best Spammer 08

Joined: 28 September 2007
Location: Sao Tome and Principe
Online Status: Offline
Posts: 16690
Posted: 29 December 2008 at 21:38 | IP Logged Quote 156-2.5-V6

Nice one Pat - I was lazy and lowered half the bumper



Edited by 156-2.5-V6 on 29 December 2008 at 21:38


__________________
Back to Top View 156-2.5-V6's Profile Search for other posts by 156-2.5-V6

Black Beauty
Tourismo (guest)
Tourismo (guest)
Avatar
Rnr-up helpful 06, Pin 07’08, Banned’09-

Joined: 25 June 2005
Location: Ireland
Online Status: Offline
Posts: 20134
Posted: 29 December 2008 at 22:44 | IP Logged Quote Black Beauty

bannowhog wrote:


Great job again Pat, yes, more black, you can never have it black enough.

I will have the gripfill tomorrow for ya.



I bought Evo-Grip today ..... hope that'll work.

Going to fit these to my car tomorrow & you can fit the others.
Back to Top View Black Beauty's Profile Search for other posts by Black Beauty

bannowhog
Tourismo (guest)
Tourismo (guest)
Avatar
Pin 08, Banned 2011-

Joined: 26 June 2008
Location: Ireland
Online Status: Offline
Posts: 1491
Posted: 29 December 2008 at 22:59 | IP Logged Quote bannowhog

Black Beauty wrote:
bannowhog wrote:


Great job again Pat, yes, more black, you can never have it black enough.

I will have the gripfill tomorrow for ya.



I bought Evo-Grip today ..... hope that'll work.

Going to fit these to my car tomorrow & you can fit the others.


Showoff

__________________
BURIED CITY CUSTOMS
MOTORCYCLE ENGINEERING
Back to Top View bannowhog's Profile Search for other posts by bannowhog Visit bannowhog's Homepage

156-2.5-V6
Senior Alfisti
Senior Alfisti
Avatar
Best Newcomer 07, Best Spammer 08

Joined: 28 September 2007
Location: Sao Tome and Principe
Online Status: Offline
Posts: 16690
Posted: 29 December 2008 at 23:06 | IP Logged Quote 156-2.5-V6

Should have bought AlfaGrip

__________________
Back to Top View 156-2.5-V6's Profile Search for other posts by 156-2.5-V6

Black Beauty
Tourismo (guest)
Tourismo (guest)
Avatar
Rnr-up helpful 06, Pin 07’08, Banned’09-

Joined: 25 June 2005
Location: Ireland
Online Status: Offline
Posts: 20134
Posted: 30 December 2008 at 08:55 | IP Logged Quote Black Beauty

Or Scoobie-Grip

overnight the Evo-Grip didn't dry much so I 'baked' one headlight this morning:



wrapped in tin foil, Gas Mark 1...... 10 min's

mmmmmmeerrrrmmmmm .... smellys lovely....got MY juices going anyways



Edited by Black Beauty on 15 January 2009 at 16:42
Back to Top View Black Beauty's Profile Search for other posts by Black Beauty

miximup
Junior Alfisti
Junior Alfisti
Avatar

Joined: 04 January 2006
Location: Northern Ireland
Online Status: Offline
Posts: 1411
Posted: 30 December 2008 at 09:04 | IP Logged Quote miximup

words spring to mind ..............but cant say them .............monday roast at pats house

__________________
THE ONLY REGRET YOU SHOULD HAVE IN LIFE IS NOT LIVING IT.............. AND YOUVE LIVED,CRIED AND SMILED WHEN YOU OWN AN ALFA
Back to Top View miximup's Profile Search for other posts by miximup

Black Beauty
Tourismo (guest)
Tourismo (guest)
Avatar
Rnr-up helpful 06, Pin 07’08, Banned’09-

Joined: 25 June 2005
Location: Ireland
Online Status: Offline
Posts: 20134
Posted: 30 December 2008 at 09:20 | IP Logged Quote Black Beauty

goes lovely with roasties & mushrooms
Back to Top View Black Beauty's Profile Search for other posts by Black Beauty

156-2.5-V6
Senior Alfisti
Senior Alfisti
Avatar
Best Newcomer 07, Best Spammer 08

Joined: 28 September 2007
Location: Sao Tome and Principe
Online Status: Offline
Posts: 16690
Posted: 30 December 2008 at 10:54 | IP Logged Quote 156-2.5-V6

Black Beauty wrote:
Or Scoobie-Grip

overnight the Evo-Grip didn't dry much so I 'baked' one headlight this morning:



wrapped in tin foil, Gas Mark 1...... 10 min's

mmmmmmeerrrrmmmmm .... smellys lovely....got MY juices going anyways



FECK!!!

I bet Marina is going mental

__________________
Back to Top View 156-2.5-V6's Profile Search for other posts by 156-2.5-V6

Black Beauty
Tourismo (guest)
Tourismo (guest)
Avatar
Rnr-up helpful 06, Pin 07’08, Banned’09-

Joined: 25 June 2005
Location: Ireland
Online Status: Offline
Posts: 20134
Posted: 30 December 2008 at 10:59 | IP Logged Quote Black Beauty

^^^^ does far stink around these parts at present

i think i have ahead-ache from the fumes
Back to Top View Black Beauty's Profile Search for other posts by Black Beauty

156-2.5-V6
Senior Alfisti
Senior Alfisti
Avatar
Best Newcomer 07, Best Spammer 08

Joined: 28 September 2007
Location: Sao Tome and Principe
Online Status: Offline
Posts: 16690
Posted: 30 December 2008 at 11:05 | IP Logged Quote 156-2.5-V6

Fit that one to Martins car

__________________
Back to Top View 156-2.5-V6's Profile Search for other posts by 156-2.5-V6
